W270 Hi-Temp Shut-Off Valve
Part #: TBD
Get Started
Request A QuoteStill Have Questions?
Contact Us
While maintaining proper temperature of your samples is ideal, it doesn't always occur. The W270 Hi-Temp Shutoff Valve was designed with this in mind.
This valve ensures that you can shut down sample flow quickly when loss of coolant or sample flow surges occur. Withstanding temperatures up to 250°F (121°C), our Hi-Temp valve begins to close when sample temperature reaches 115°F (46°C) and completely closes when temperatures reach 125°F (52°C) – all without operator intervention.
- The W270 Shutoff Valve is compact with dimensions of 1.375 in x 3.5 in (35 mm x 89 mm).
- Made with corrosion-resistant stainless steel, operators can be assured of minimal sample contamination or product degradation.
- This Hi-Temp valve requires no reset or operator involvement, ensuring piece of mind for your team.
| Wetted Materials | Pressure Rating | Temperature Rating | Pressure Drop |
|---|---|---|---|
|
316 SS, Vitron, PEEK
|
4400 PSI (303 bar) | 250°F (121°C) | Cv=0.21 |
